1. The spindle speed of the stranding machine can reach 3000 rpm.
2. Automatic Tension Control: During stranding, the take-up tension needs to continuously increase from the bottom of the reel to a full reel. This machine can automatically track and adjust the take-up tension, ensuring uniform tension throughout the entire reel. At the same time, the machine can adjust the tension without stopping.
3. The machine is equipped with three pressing devices to ensure the roundness of the conductor after stranding and to reduce the wear of the insulation material.
4. The main engine is lubricated with engine oil and cooled by natural circulation, effectively extending the service life of the spindle bearings. The wiring system uses a new structure, where the wire passes directly from the spindle guide wheel to the bow belt, eliminating the scratches and skipping of strands caused by faults in the corner guide wheel on the aluminum plate.
5. The whole machine uses synchronous belt transmission, with no lubrication points inside the machine, maintaining internal cleanliness. The twisted wires have no oil contamination, making it suitable for conducting wire twisting of wire types with high surface cleanliness requirements.
6. To adjust the twist pitch, you only need to replace one guide wheel; to adjust the twist direction, you just need to move the reversing lever. The operation is simple, thereby reducing operator errors and work intensity. All machine bearings are selected from well-known Japanese brands, and the bow tapes are made from new materials with good flexibility, preventing strand jumping due to vibration during high-speed operation. The frequency converter, PLC, magnetic powder clutch, electromagnetic brake, hydraulic jack, and other components are all selected from well-known imported brands to reduce failure rates and maintenance costs.
